Here is the info for the advanced collector and enthusiast. Useful information

supplied from many sources including members of Spitfire Spares.



26 codes
--------------------------------------------------------------------------------
MOD
ref Airframe
type--------------------------------------------------------------------------------26AE
Chipmunk T MK 10
26AF Hurricane including Tempest spares
26AJ Spitfire & Seafire
26AL Sunderland 5
26AN Oxford 1 & 2
26AQ Sea Hawk
26AT Wellington B10 T10 & 18
26BA Halifax
26BJ Martinet 1
26BM Attacker F & B
26BN Proctor 3 & 4
26BP Beaufighter TT10
26BT Barracuda 3
26BU Gannet AS1 & T2
26BV Sycamore HR
26BW Dominie 1
26BX Typhoon including Tempest spares
26BY Mosquito & Sea Mosquito
26BZ Firefly
26DA Javelin F (AW)
26DB Whirlwind & Westland Sikorsky S55
26DC Vulcan B
26DD Anson
26DE Victor B1
26DF Beverley C
26DG Seamew
26DH Scimitar F1
26DJ Belvedere HC
26DK Lightening
26DL Comet 2
26DM Britannia
26DN Gnat Trainer
26DP Alouette (British spares)
26DQ Basset CC1
26DR Beaver AL
26DV Venom FB NF & Sea Venom FAW
26EA Lancaster , Lincoln 2 & York C1
26ED Horsa 2
26EH Meteor F8 & T7
26EM Sea Otter
26EN Auster
26ER Tempest 2, TT5 & 6
26ET Meteor NF & TT20
26EV Vickers 1000 Transport Aircraft
26EW Hornet & Sea Hornet
26FA Brigand
26FC Vampire & Sea Vampire
26FH Sea Fury
26FK Hastings
26FL Valetta & Viking
26FM Prentice T1
26FN Devon C
26FP Shackleton
26FR Winged Targets
26FU Balliol & Sea Balliol
26FV Dragonfly HC & HR
26FW Heron
26FX Hunter & De Havilland N139D(Type 110)
26FY Sea Vixen
26FZ Canberra
26GA Bristol standard parts for Beaufighter, Brigand & Buckmaster
26KK Osprey
26LK Hercules CMK1
26MM SA330E Anglo-French Helicopter
26NA Buccaneer
26NB Belfast
26PH Phantom GRF
26PJ Jet Provost T
26PN Percival Provost T1
26PP Pembroke HC, C1 & Sea Prince
26RA Jaguar
26SA Pioneer CC1
26SH Sea King
26SK Skeeter
26SR Valiant B
26SS Swift
26SW Scout [& Wasp]
26TA Andover
26TD Dominie T
26TP Twin Pioneer
26TT Tiger Moth 2
26TV Varsity T1
26UU Wellington 1
26V Hart DB & India & T
26VA Harrier GR
26VC VC10C
26WA Argosy
26WX Wessex

26A - Swordfish
26AAA - Hector
26AC - Blenheim
26AH - Botha
26AK - Henley
26ALS - Tucano airframe
26AM - Hampden
26AR - Botha
26AS - Mentor and Magister
26AU - Lysander
26AV - Lerwick
26AW - Bombay
26AX - Manchester/Lancaster
26AY - Beaufort
26AZ - Defiant
26BE - Fulmar
26BF - Stirling
26BG - Harvard
26BH - Hudson
26BK - Albermarle
26BL - Whirlwind(fighter)
26BQ - Queen Wasp
26BS - B45 Tornado
26BV(1) - Vega Gull & Q6
26BW - Dominie and Rapide
26C - Ripon
26CB - Sioux
26CC - Hinaidi II
26CCC - Gladiator
26C* - Impressed aircraft
26CJ - F86 Sabre
26CP - Moth Minor
26D - Iris
26DD(1) - Dart
26DS - TSR2
26DY - Venom
26E - Fury
26EA - Lancaster/Lincoln
26EC - Warwick
26EE - Sedburgh
26EF - Hengist
26EG - Welkin
26EJ - Welkin
26EL - Firebrand
26EQ - Eton
26EX - Messenger
26EY - Kirby Cadet and Grasshopper
26EZ - Buckingham and Buckmaster
26F - Vimy
26FD - Spiteful
26FE - Prefect Glider
26FF(1) - Grebe
26FF(2) - Marathon
26FJ - Sturgeon
26FS - Wyvern
26FT - Athena
26G - Wapiti
26GG - Rangoon
26GRP - GRP Glider, Janus, ASW19, ASW21
26HH - Tomtit
26J - Whitley
26JJ - Battle
26JU - Expeditor
26K - Bulldog(Bristol)
26L - Nimrod(Hawker)
26LE - Gazelle
26LX - Lynx
26M - Cloud
26MA - Tornado GR1/F3
26MH - Vigilant
26MR - Jetstream
26N - Southampton
26NN - Gauntlet
26NS - Bulldog T1
26P - Audax
26PL - Hawk
26PN - Percival
26PP(1) - Avro 504K
26PP(2) - Test Benches
26PPA - Phantom Potential Assets
26Q - Tutor(Avro)
26QF - BAe airframe spares
26QQ(1) - Gauntlet
26QQ(2) - Gannet
26R - Sidestrand
26RDK - Lightning
26RM - Non-RAF Tornado common items(repairable)
26RP - Phantom recce pod
26RSH - Sea King airframe
26S - Vildebeast
26SG - swallow
26SP - Puma
26SS - Victoria(1)
26T - Hyderabad and Hinaidi
26TC - Tucano
26TS - Tristar
26TT(2) - to 26AE
26VB - Harrier GR5/7/10
26VN - Sea Harrier
26VV - Horsley
26W - Demon
26WW - Siskin
26Y - Flycatcher and Harrow
26YY - Gordon and Seal/A1F
26Z - Virginia
26ZZ - Atlas

'126' Codes (US Spares)
--------------------------------------------------------------------------------MOD
Ref. Airframe
--------------------------------------------------------------------------------CB Sioux
CK Chinook
HA Baltimore
HF Boston
HG Buffalo
HH Bermuda
HJ Vigilant
HK Catalina
HL Liberator
HO Lightening
HP Maryland
HT Vengence
HU Goose
JH Lodestar
JJ Argus
JL Mitchell
JM Marauder
JP Mariner
JQ Dakota
JU Expeditor
JV Coronado
JZ Hadrian
KB Ventura
KC Piper Club
KG Cornell
KN Expeditor (US)
KL Hoverfly

'36' Codes Engine Spares
--------------------------------------------------------------------------------MOD
Ref. Engine
--------------------------------------------------------------------------------36AB
Bombardier 20801
36AC Olympus
36AD Viper
36AE Conway
36AF Rover airborne aux power plant
36AH Proteus
36AK Orpheus
36AL Alvis Leonides
36BB Artouste Patouste & Turmo
36BC Nimbus
36DD Rolls Royce Merlin and tools
36DE Gnome
36DG Gyron Junior
36DT Dart
36FF Gypsy Major & Gypsy Queen & De Havilland tools
36HH Rolls Royce Griffon and tools
36HS Hawker Siddeley fuel control equipment
36JJ Derwent turbine engines
36KK Goblin 2 & 3
36LL Lucas fuel equipment
36M Sabre and Napier repair tools
36MM Dowty fuel system equipment
36NG Gazelle
36PG Pegasus
36PP Python 2 & 3 engine
36Q Rolls Royce Nene jet
36R Bristol Mercury, Centaurus & Hercules tools
36SN Rolls Royce Spey Mk201/202
36SS Sapphire
36ST Rolls Royce Spey Mk250
36SY Rolls Royce Spey
36TN Rolls Royce Tyne
36TT Ghost
36TU Rolls Royce Turmo III
36U Cheetah & Armstrong Siddeley tools
36VV Rolls Royce Avon jet
36W Centaurus & Bristol tools
36WW Double Mamba

Electrical Equipment
--------------------------------------------------------------------------------MOD
Ref. Component
--------------------------------------------------------------------------------5A Ground
Lighting and Miscellaneous Equipment
5B Aircraft Wiring Assemblies
5CW Aircraft Electrical Switches, Switchboxes, Relays and Accessory Items
5CX Aircraft Electrical Lamps, Indicators, Lampholders and Accessory Items
5CY Aircraft Electrical Plugs, Sockets, Circuit Markers, Suppressors and Accumulator
Cut-outs
5CZ Aircraft Electrical Miscellaneous Stores
5D Aircraft Armament Electrical Stores
5E Cable and Wire Electrical Stores
5F Insulating Materials Electrical Stores
5G Special Ground Equipment
5H Standard Wiring System
5J Batteries Primary and Secondary
5K Electrical A.G.S and Bonding Stores
5L Electric Lamps
5P Ground Charging, Transforming Equipment and Motors
5Q Ammeters, Micro-ammeters, Milli-ammeters, Voltmeters and Milli-voltmeters
5S Strip Wiring Components
5UA Aircraft Engine and Air Driven Electrical Current Producing Equipment and Spares
5UB Aircraft Electrically Driven Electrical Current Producing and Transforming Equipment
and Spares
5UC Aircraft Electrical Current Control Equipment and Spares
5UD Aircraft Electrical Motors, Blowers and Spares
5UE Aircraft Electrically Driven Pumps, Accessories and Spares
5V Aircraft Electrical Domestic Equipment
5W Aircraft Electrical Actuators, Accessories and Spares
5X Component Parts of Wiring Assemblies

Radio, Radar, Telephone and Telegraphic Equipment
--------------------------------------------------------------------------------MOD
Ref. Description
--------------------------------------------------------------------------------10A
Miscellaneous Radio (Wireless) Equipment
10AB Miscellaneous Radio (Radar) Equipment
10AC Unassembled Items peculiar to Radio with Generic Headings similar to those in Sections
28 and 29
10AD Items and Assemblies performing Circuit Functions (Nomenclature commencing Letters
A-K)
10AD Items and Assemblies performing Circuit Functions (Nomenclature commencing Letters
L-Z)
10AF Calculating, Indicating and Measuring Equipment
10AG Tools and Tool Boxes peculiar to Radio
10AH Telephone Head Equipment, Microphones and Receivers
10AJ Mountings and their Component Parts
10AK Dials, Handles, Knobs, Plates, Escutcheon, Pointers, Press buttons and Scales
10AL Screens and Insulating Components and their Assemblies
10AM Labels (Radio)
10AP Boxes, Cases, Covers and Trays, other Cases, Transit
10AQ Furniture, Tentage, textile Materials and Ventilator Equipment, peculiar to Radio
10AR Machinery, Machine and Mechanical Parts other than those in Section 10AC
(Nomenclature commencing Letters A-K)
10AR Machinery, Machine and Mechanical Parts other than those in Section 10AC
(Nomenclature commencing Letters L-Z)
10AT Windows and Visors
10AU Strip Metallic
10B Radio (Wireless and Radar) Aerial and Mast Equipment and Insulators
10BB Radio (Radar) Aerial and Mast Equipment and Insulators
10C radio Chokes, Capacitors and Inductors (see also Joint-Service Catalogue)
10CV Joint Service Common Valves
10D Radio (Wireless and Radar) Equipment, Modulators, Panels, Receivers, Transmitters etc.
10DB Radio (Radar) Equipment, panels, Power Units, Racks, Receivers and Transmitters
10E Magnets and Radio Valves (Industrial Types)
10F Radio (Wireless and Radar) Starters and Switch Gear
10FB Radio (radar) starters and Switch Gear
10G Ground Telephone and Telegraph Equipment
10GP Ground Telephone and Telegraph Equipment - Post Office Pattern
10H Radio Connectors, Discs Indicating, Fuses, Leads, Plugs and Sockets and Ancillary
Parts,
Holders and Terminals.
10HA Radio (Wireless and Radar) Connectors, Cords Instrument and Leads
10J Radio Remote Controls
10K Radio (Wireless and Radar) Power Units and Transformers
10KB Radio (Radar) Power Units and Transformers
10L Radio (Wireless and Radar) Control Units
10LB Radio (Radar) Control Units
10P Radio (Wireless and Radar) Filter and Receiver Units
10PB Radio (Radar) Filter and Receiver Units
10Q Radio (Wireless and Radar) Indicating Units
10QB Radio (Radar) Indicating Units
10R Radio (Wireless and Radar) Transmitter Units
10RB Radio (Radar) Transmitter Units
10S Radio (Wireless and Radar) Test Equipment
10SB Radio (Radar) Test Equipment
10T Radio Monitors and Wavemeters
10U Radio (Wireless and Radar) Amplifying Units, Loudspeakers and Sound Reproduction
Equipment
10UB Radio (Radar) Amplifying Units and Loudspeakers
10V Radio (Wireless and Radar) Oscillator Units
10VB Radio (Radar) Oscillator Units
10W Radio Resistors and miscellaneous Spares
10X Radio Crystal Units
10Y Cases Transit (general Radio purposes)

General Ground and Air Armament Equipment
--------------------------------------------------------------------------------MOD
Ref. Description
--------------------------------------------------------------------------------9 Bomb
and Torpedo Sights
9A Aircraft Towed Target Gear
9B Armament Ground Instructional Equipment
11A Aircraft Bomb Gear
11C Rocket Projector Gear
40H Gun Turret Cases and Airtight Containers
50A Aircraft Gun Turrets
50CC Boulton Paul Gun Turret and Gun Mounting Tools
50DD Bristol Gun Turret Tools
50EE Frazer Nash Gun Turret Tools
50H Aircraft Gun Turret Maintenance Equipment
50J Free Gun Mountings

Instruments, Models, Navigation and Plotting Equipment, Aircraft Automatic Pilots
--------------------------------------------------------------------------------MOD
Ref. Description
--------------------------------------------------------------------------------6A
Aircraft Engine and Flying Instruments, Accessories and Spares
6B Aircraft Navigation Equipment, Accessories and Spares
6C Instrument Test Equipment, Tools, Accessories and Unit Equipment Spares
6D Aircraft Gaseous Apparatus and Ancillary Equipment
6E Miscellaneous Instruments, Accessories and Unit Servicing Spares
6H Aircraft Automatic Pilots, Marks 4 and 8, Major Components, Servicing Spares and Tools
6J Aircraft Automatic Pilots, Types A3 and A3A and A.L.1, Major Components, Servicing
Spares and Tools
6S Automatic Stabilisers, Major Components, Servicing Spares and Tools
6T Aircraft Automatic Pilots, Marks 9, 10, 10A, 13, SEP 2, 14 and 17, Major Components,
Servicing Spares and Tools
6W Instrumemnt Ancillaries to Radio Equipment
6Z Radio activity Detection Equipment and Accessories, Unit and Major Servicing Spares
13 Drawing Instruments
52 Recognition Models
54A Plotting Equipment

Photographic Equipment
--------------------------------------------------------------------------------MOD
Ref. Description
--------------------------------------------------------------------------------14A
Cameras
14B Photographic Processing Equipment, Enlargers and Accessories
14C Projection, Assessing Apparatus and Epidiascopes
14H Photographic Test Apparatus

General Aircraft Equipment
--------------------------------------------------------------------------------MOD
Ref. Component
--------------------------------------------------------------------------------6F
Aircraft Personnel Equipment
15A Man-carrying Parachutes
15C Equipment-dropping and Sea-rescue Apparatus
15D Air Sea Rescue and Equipment, and Supply-dropping Parachutes
25A Propellers
25B Aircraft Radiators
25D Spinners for Fixed Pitch Propellers and Fairey Spares for Metal Propellers
27A Aircraft Wheel Equipment
27B Aircraft Air and Oil Filters, Fuel and Oil Coolers
27D Miscellaneous Aircraft Cover Equipment
27F Aircraft Pumps and fuelling Equipment (Airborne)
27G Aircraft Brake System Equipment
27H Miscellaneous Aircraft Equipment
27J Aircraft Control Handles with Gun, Camera, R.P. and Brake Operating Mechanisms
27K Teleflex Aircraft Remote Control Equipment
27KA Exactor Aircraft Remote Control Equipment
27KB Aircraft Controls - Roller Chains
27KD Pressurised Cabin Equipment - Normalair
27M Aircraft Hydraulic and Undercarriage Equipment - Lockheed
27N Airborne Fire Fighting Equipment
27R B.L.G. Oleo Leg Equipment
27S Standard Ball and Roller Bearings other than M.T.
27T Controllable Gills
27U Airborne Heaters
27UA Aircraft Cabin Cooling Equipment
27V Aircraft Controls - Teddington
27VA Aircraft Controls - Dunlop
27VC Aircraft Controls - Palmers
27W Aircraft Hydraulic and Undercarriage Equipment, Standard Design
27WW Aircraft Windscreen Wiper Equipment
27Z Turner Duplex Hand Pumps for Aircraft Hydraulic Systems
27ZA Exactor Self Sealing Couplings

A.G.S. and General Hardware
--------------------------------------------------------------------------------MOD
Ref. Description
--------------------------------------------------------------------------------28D Bolts
A.G.S.
28E Clips A.G.S.
28F Couplings A.G.S.
28FP Aircraft Fastener and Quick Release Pins
28G Eyebolts A.G.S.
28H Ferrules A.G.S.
28J Filler Caps and Fuel Filters A.G.S.
28K Fork Joints A.G.S.
28L Locknuts, Lockwashers A.G.S.
28M Nuts A.G.S.
28N A.G.S. Miscellaneous A to O
28P Pins A.G.S.
28Q Rivets A.G.S.
28R A.G.S. Miscellaneous P to R
28S Screws A.G.S. Miscellaneous A to O
28T Studs A.G.S.
28U Trunnions and Turnbuckles A.G.S.
28V Unions A.G.S.
28W Washers A.G.S.
28X Wire A.G.S.
28Y A.G.S. Miscellaneous S to Z
29A Bolts and Nuts, General Hardware
29B Screws, General Hardware
29C Eyelets, Roves, Screw Cups, Washers, General Hardware
29E Pins, Woodruff Keys, General Hardware
29F Rivets, General Hardware


Workshop, Ground, Hangar, Marine and Compressed Gas Equipment
--------------------------------------------------------------------------------MOD
Ref. Description
--------------------------------------------------------------------------------4A
Workshop Equipment
4C Airfield Equipment
4F Air Compressors and Servicing Trolleys
4G Aircraft Servicing and Ground handling Equipment
4K General Ground Equipment (including Refuelling Equipment)
4N Sparking Plug Testing and Servicing Equipment
4FZ Air Compressor Spares
71B Plants (Mobile, Transportable and Static) and Plant Accessories

Manufacturer Codes/inspectors stamps:

AS = Airspeed
AW = Armstrong Whitworth
R3 = Avro
BP = Boulton Paul (possibly EP)
FB = Bristol
DH = de Havilland
DHB - de Havilland, Broughton
DHC - de Havilland, Christchurch
DHL - de Havilland, Lostock (usually propellers)
EEP = English Electric Preston
F8 = Fairey Engineering
GAL = General Aircraft Limited
G5 = Gloster
HA = Hawker – also 41H?
HP = Handley Page
MCO = Morris Cowley Oxford
PAC = Percival Aircraft Corporation
PPA = Miles (Phillips & Powis)
R = Republic
SB = Short Brothers
SFR = Rootes Speke
SR = Saunders Roe
SHB = Short & Harland Belfast
SHR = Short & Harland Rochester
TAY = Taylorcraft
VA = Victory Aircraft
VACB = Vickers Armstrong Castle Bromwich
VACH = Vickers Armstrong Chester
VABL = Vickers Armstrong Blackpool
WA = Westland



Miscellaneous Codes:

AGS = Aircraft General Standard (Often on nuts and bolt heads)
ALCLAD = Aluminium (Or “Alooominum” if from former colonies!)
ALCOA = Aluminium Corporation of America
PSC = Pressed Steel Company

Manufacturer Codes/inspectors stamps:

AS = Airspeed
AW = Armstrong Whitworth
BP = Boulton Paul (possibly EP)
C = Canadair (inspector's id number is arranged vertically within the C) (Sabre Mk.4 & Mk.6)
CAA = Commonwealth
Aircraft
CCF = Canadian Car & Foundary (Hurricane Mk.IIB and Mk.IIC)
CH = Claudel Hobson
DH = de Havilland
DHB = de Havilland, Broughton
DHC = de Havilland, Christchurch
DHL = de Havilland, Lostock (usually propellers)
EEP = English Electric Preston
FB = Bristol
F8 = Fairey Engineering
FL = Folland
FM = Fairey
GAL = General
Aircraft Limited
G5 = Gloster
GHCH = George Hardman Ltd. of Haywood Lancs
HA = Hawker – also 41H?
HP = Handley Page
HPL = High Speed Plastics Ltd. of Bangor, N.Wales
LAP = London
Aircraft Production Group (Halifax)
LBSB = Austin Motors Longbridge
LTAF = London
Aircraft Production Group (Halifax)
MCO = Morris Cowley Oxford
N = Noorduyn (UC-64 and Harvard)
PAC = Percival
Aircraft Corporation
PP = Miles
PPA = Miles (Phillips & Powis)
R = Republic
R2 = Rootes Secturities (Blenheim, Beaufighter and Halifax)
R3 = Avro
RR = Rolls Royce
RY = Avro (Yeadon)
SB = Short Brothers
SFR = Rootes Speke
SR = Saunders Roe
SHB = Short & Harland Belfast
SHR = Short & Harland Rochester
TAM = Tampier (Bloctube Controls Ltd. of Aylesbury)
TAY = Taylorcraft
VA = Victory
Aircraft
VACB = Vickers Armstrong Castle Bromwich
VACH = Vickers Armstrong Chester
VABL = Vickers Armstrong Blackpool
WA = Westland



Aircraft
Part Codes:

P39 = Airacobra (Bell)
AW41 = Albermarle Mk1
652A = Anson (All Mk’s)
660 = Argosy
UC61 = Argus Mk1 (Fairchild)
UC61A= Argus Mk II
UC61K= Argus Mk III
55, 56 = AT-6
77, 78 = AT-6A
84 = AT-6B
88 = AT-6C
121 = AT-6D
168 = AT-6G
804 = AT-11
54576 = AT-17
701 = Avro Athena T2
540 = Avro 504K
582 = Avro 504N

187 = Baltimore (Martin)
PD = Battle
PC = Battle
PA = Battle
156 = Beaufighter Mk1F
152 = Beaufort
126 = Beaufort DAP
192 = Belvedere (Westland)
B101 = Beverley (Blackburn) C1
555 = Bison
142M = Blenheim Mk IF
149 = Blenheim Mk Ib
160 = Blenheim Mk V
130A = Bombay
12 or 13 = Boomerang (CAC)
B26 = Botha
164 = Brigand
F2A = Bristol Fighter
19 = BT-9
19A = BT-9A
23 = BT-9B
29 = BT-9C
63, 74, 79 = BT-13
B103 = Buccaneer
B339E = Brewster Buffalo
105A = Bristol Bulldog Mk II & IIa

EA3 = Canberra B2
EA2 = Canberra PR3
EA4 = Canberra Mk24
SC4 = Canberra U/D 10
28 = Catalina Mk I
CH47 = Chinook HC1
C1 = Chipmunk T10
60 = Cirrus Moth Mk I & II
106 = Comet Mk I – IV
20 = Commando

C47 = Dakota Mk I
C53 = Dakota Mk II
C47A = Dakota Mk III
C47B = Dakota Mk IV
P82 = Defiant
104 = Devon
89A = Dominie Mk I
‘(B = Dominie Mk II

AS10 = Envoy Mk III
229 = Fortress Mk I

60M = Gipsy Moth

HP57 = Halifax Mk I
HP59 = Halifax Mk II
HP61 = Halifax Mk III
HP63 = Halifax Mk IV
HP63 = Halifax Mk V
HP70 = Halifax Mk VIII
HP71 = Halifax Mk IX
HP52 = Hampden Mk I
HP54 = Harrow
16 = Harvard I
66 = Harvard II
88 = Harvard IIa
AT16 = Harvard IIb
HP67 = Hastings
HP94 = Hastings C4
DB7 = Havoc I
DB7A = Havoc Mk II
75 = Hawk (Curtis)
P1182 = Hawk (BAe)
C130K = Hercules (Lockheed)
14 = Heron
HP50 = Heyford
103 = Hornet
87 = Hornet Moth
AS51 = Horsa (Also marked AS58)
16 = Hudson
L-214 = Hudson Mk I
L-414 = Hudson Mk II-VI
P1067 = Hunter Mk I
P1099 = Hunter Mk6
P1101 = Hunter T7

TypeS = Jaguar
TypeM = Jaguar T2
121 = Jaguar
GA5 = Javelin
145 = Jet Provost

87 = Kittyhawk (P-40)

683 = Lancaster (All Mks)
691 = Lancastrian
32 = Liberator
22 = Lightning (P-38)
P1B = Lightning Mk IF
P25 = Lightning Mk 2F
P26 = Lightning Mk 3F
P11 = Lightning T4
P27 = Lightning T5
694 = Lincoln
P8 = Lysander

M14 = Magister Mk I
679 = Manchester
179 = Marauder
M25 = Martinet TT1
M9 = Master Mk I
M19 = Master Mk II
M27 = Master Mk III
M16 = Mentor
G41A = Meteor Mk I
G41F = Meteor F4
G43 = Meteor T7
G41K = Meteor F8
G41L = Meteor FR9
G41M = Meteor PR10
NA62B = Mitchell Mk I
NA82 = Mitchell II
NA-108 = Mitchell III
98 = Mosquito (All Mks)

73 = Mustang I (Also NA83)
91 = Mustang Ia
97 = A-36 Apache (with dive brakes)
99 = P-51A / Mustang II
102 = Mustang III
103 = P-51C (early version) / Mustang III
104 = P-51B (later version) / Mustang III
106 = Mustang
109 = Mustang IV
111 = P-51C (later version) / Mustang III
111 = P-51K-NT (early Dallas-built = Mustang IVA
122 = P-51D-NA (later version) / Mustang IV
124 = P-51D-NT (late version Dallas built) / Mustang IV

26 = Neptune
HS801 = Nimrod (BAe)

AS10 = Oxford MkI & II
AS46 = Oxford MkV

P66 = Pembroke
F-4 = Phantom
P28 = Proctor I
P30 = Proctor II
P34 = Proctor III
P31 = Proctor IV

82B = Queen Bee (Pilotless?)

C1-13 = Sabre (F-86)
696 = Shackleton
382 = Spiteful
300 = Spitfire Mk I; Ia; Ib
329 = Spitfire Mk IIa & IIb
375 = Spitfire Mk IIc
353 = Spitfire Mk IV
332 = Spitfire Mk Vb
331 = Spitfire Mk Vb
349 = Spitfire Mk Vc & LF Vb
352 = Spitfire F Vb
351 = Spitfire Mk VII
359 = Spitfire Mk III
361 = Spitfire Mk IX
362 & 387 = Spitfire Mk X
365 = Spitfire Mk XI
366 = Spitfire Mk XII & XIII
367 & 353 = Spitfire Mk XIII
369 & 379 = Spitfire Mk XIV & XIVe
380 = Spitfire Mk XVI
394 = Spitfire Mk XVIII
389 & 390 = Spitfire Mk XIX
356 = Spitfire Mk F21; F22 & F24
SB29 = Stirling
S25 = Sunderland
541 = Swift (Shorts)
546 = Swift (Supermarine)
171 = Sycamore HA12

82 = Tiger Moth
81A-1 = Tomahawk Mk I
81A-2 = Tomahawk Mk II
621 = Tutor (Avro)
89 & 93 = Thunderbolt

637 = Valetta
706 & 710 = Valiant
100 = Vampire Mk F1; F3; F5; F9
113 = Vampire NF10
115 = Vampire T11
668 = Varsity
112 = Venom
V146 = Ventura
237 = Ventura Mk V
HP80 = Victor
498 = Viking C2
FB27 = Vimy Mk IV
698 = Vulcan

03 = Wackett (CAC)
236 = Walrus
462 = Warwick ASR Mk I
413 & 611 = Warwick II
460 = Warwick III
474 & 475 = Warwick V
485 = Warwick ASR Mk VI
345 = Washington B1
P14 = Welkin
287 = Wellesley
285 & 290 = Wellington I
408 & 409 = Wellington Ia
415 & 450 = Wellington Ic
298 & 406 = Wellington II
417 & 440 = Wellington III
410 & 424 = Wellington IV
407 & 421 = Wellington V
442 & 449 = Wellington VI
429 = Wellington VIII
440 = Wellington X
454 & 458 = Wellington XI
455 = Wellington XII
466 = Wellington XIII
467 = Wellington XIV
P9 = Whirlwind
AW = Whitley
SP = Whitley
01 or 02 = Wirraway (CAC)
244 = Wildebeeste I
258 = Wildebeeste II
267 = Wildebeeste III
286 = Wildebeeste IV

685 = York C1


Air Ministry Equipment Codes:

5A = Ground Lighting and Miscellaneous Equipment
5B = Aircraft Wiring Assemblies
5CW = Aircraft Electrical Switches, Switchboxes, Relays and Accessory Items
5CX = Aircraft Electrical Lamps, Indicators, Lampholders and Accessory Items
5CY = Aircraft Electrical Plugs, Sockets, Circuit Markers, Suppressors and Accumulator Cut-outs
5CZ = Aircraft Electrical Miscellaneous Stores
5D = Aircraft Armament Electrical Stores
5E = Cable and Wire Electrical Stores
5F = Insulating Materials Electrical Stores
5G = Special Ground Equipment
5H = Standard Wiring System
5J = Batteries Primary and Secondary
5K = Electrical A.G.S and Bonding Stores
5L = Electric Lamps
5P = Ground Charging, Transforming Equipment and Motors
5Q = Ammeters, Micro-ammeters, Milli-ammeters, Voltmeters and Milli-voltmeters
5S = Strip Wiring Components
5UA = Aircraft Engine and Air Driven Electrical Current Producing Equipment and Spares
5UB = Aircraft Electrically Driven Electrical Current Producing and Transforming Equipment and Spares
5UC = Aircraft Electrical Current Control Equipment and Spares
5UD = Aircraft Electrical Motors, Blowers and Spares
5UE = Aircraft Electrically Driven Pumps, Accessories and Spares
5V = Aircraft Electrical Domestic Equipment
5W = Aircraft Electrical Actuators, Accessories and Spares
5X = Component Parts of Wiring Assemblies
6 = Nav. & optical Equipt.
6A = Aircraft Instruments
6D = Oxygen Equipment
6F = Aircraft Personnel Equipt.
7; 8, 9 = Aircraft Armaments
9A = Aircraft Towed Target Gear
9B = Armament Ground Instructional Equipment
10A = Miscellaneous Radio (Wireless) Equipment
10AB = Miscellaneous Radio (Radar) Equipment
10AC = Unassembled Items peculiar to Radio with Generic Headings similar to those in Sections 28 and 29
10AD = Items and Assemblies performing Circuit Functions (Nomenclature commencing Letters A-K)
10AD = Items and Assemblies performing Circuit Functions (Nomenclature commencing Letters L-Z)
10AF = Calculating, Indicating and Measuring Equipment
10AG = Tools and Tool Boxes peculiar to Radio
10AH = Telephone Head Equipment, Microphones and Receivers
10AJ = Mountings and their Component Parts
10AK = Dials, Handles, Knobs,Plates, Escutcheon, Pointers, Pressbuttons and Scales
10AL = Screens and Insulating Components and their Assemblies
10AM = Labels (Radio)
10AP = Boxes, Cases, Covers and Trays, other Cases, Transit
10AQ = Furniture, Tentage, textile Materials and Ventilator Equipment, peculiar to Radio
10AR = Machinery, Machine and Mechanical Parts other than those in Section 10AC
(Nomenclature commencing Letters A-K)
10AR = Machinery, Machine and Mechanical Parts other than those in Section 10AC
(Nomenclature commencing Letters L-Z)
10AT = Windows and Visors
10AU = Strip Metallic
10B = Radio (Wireless and Radar) Aerial and Mast Equipment and Insulators
10BB = Radio (Radar) Aerial and Mast Equipment and Insulators
10C = radio Chokes, Capacitors and Inductors (see also Joint-Service Catalogue)
10CV = Joint Service Common Valves
10D = Radio (Wireless and Radar) Equipment, Modulators, Panels, Receivers, Transmitters etc.
10DB = Radio (Radar) Equipment, panels, Power Units, Racks, Receivers and Transmitters
10E = Magnets and Radio Valves (Industrial Types)
10F = Radio (Wireless and Radar) Starters and Switch Gear
10FB = Radio (radar) starters and Switch Gear
10G = Ground Telephone and Telegraph Equipment
10GP = Ground Telephone and Telegraph Equipment - Post Office Pattern
10H = Radio Connectors, Discs Indicating, Fuses, Leads, Plugs and Sockets and Ancillary Parts,
Holders and Terminals.
10HA = Radio (Wireless and Radar) Connectors, Cords Instrument and Leads
10J = Radio Remote Controls
10K = Radio (Wireless and Radar) Power Units and Transformers
10KB = Radio (Radar) Power Units and Transformers
10L = Radio (Wireless and Radar) Control Units
10LB = Radio (Radar) Control Units
10P = Radio (Wireless and Radar) Filter and Receiver Units
10PB = Radio (Radar) Filter and Receiver Units
10Q = Radio (Wireless and Radar) Indicating Units
10QB = Radio (Radar) Indicating Units
10R = Radio (Wireless and Radar) Transmitter Units
10RB = Radio (Radar) Transmitter Units
10S = Radio (Wireless and Radar) Test Equipment
10SB = Radio (Radar) Test Equipment
10T = Radio Monitors and Wavemeters
10U = Radio (Wireless and Radar) Amplifying Units, Loudspeakers and Sound Reproduction Equipment
10UB = Radio (Radar) Amplifying Units and Loudspeakers
10V = Radio (Wireless and Radar) Oscillator Units
10VB = Radio (Radar) Oscillator Units
10W = Radio Resistors and miscellaneous Spares
10X = Radio Crystal Units
10Y = Cases Transit (general Radio purposes)
11A = Aircraft Bomb Gear
11C = Rocket Projector Gear
12A= Bombs (Live)
12B= Bombs (Dummy)
12C= Ammunition
12E = Torpedoes
12F= Misc. Armament
14 = Photo Equipment
15A = Man-carrying parachute Equip.
15C= Equipt Drop & Sea-Dropping Apparatus
15D = Supply Drop & ASR Equipt.
22C= Flying Clothing
27C= Survival Equipment
40H Gun Turret Cases and Airtight Containers
50A Aircraft Gun Turrets
50CC Boulton Paul Gun Turret and Gun Mounting Tools
50DD Bristol Gun Turret Tools
50EE Frazer Nash Gun Turret Tools
50H Aircraft Gun Turret Maintenance Equipment
50J Free Gun Mountings


26AE Chipmunk T MK 10
26AF Hurricane including Tempest spares
26AJ Spitfire & Seafire
26AL Sunderland 5
26AN Oxford 1 & 2
26AQ Sea Hawk
26AT Wellington B10 T10 & 18
26BA Halifax
26BJ Martinet 1
26BM Attacker F & B
26BN Proctor 3 & 4
26BP Beaufighter TT10
26BT Barracuda 3
26BU Gannet AS1 & T2
26BV Sycamore HR
26BW Dominie 1
26BX Typhoon including Tempest spares
26BY Mosquito & Sea Mosquito
26BZ Firefly
26DA Javelin F (AW)
26DB Whirlwind & Westland Sikorsky S55
26DC Vulcan B
26DD Anson
26DE Victor B1
26DF Beverley C
26DG Seamew
26DH Scimitar F1
26DJ Belvedere HC
26DK Lightening
26DL Comet 2
26DM Britannia
26DN Gnat Trainer
26DP Alouette (British spares)
26DQ Basset CC1
26DR Beaver AL
26DV Venom FB NF & Sea Venom FAW
26EA Lancaster , Lincoln 2 & York C1
26ED Horsa 2
26EH Meteor F8 & T7
26EM Sea Otter
26EN Auster
26ER Tempest 2, TT5 & 6
26ET Meteor NF & TT20
26EV Vickers 1000 Transport Aircraft
26EW Hornet & Sea Hornet
26FA Brigand
26FC Vampire & Sea Vampire
26FH Sea Fury
26FK Hastings
26FL Valetta & Viking
26FM Prentice T1
26FN Devon C or Sea Heron
26FP Shackleton
26FR Winged Targets
26FU Balliol & Sea Balliol
26FV Dragonfly HC & HR
26FW Heron
26FX Hunter & De Havilland N139D(Type 110)
26FY Sea Vixen
26FZ Canberra
26GA Bristol standard parts for Beaufighter, Brigand & Buckmaster
26KK Osprey
26LK Hercules CMK1
26MM SA330E Anglo-French Helicopter
26NA Buccaneer
26NB Belfast
26PH Phantom GRF
26PJ Jet Provost T
26PN Percival Provost T1
26PP Pembroke HC, C1 & Sea Prince
26RA Jaguar
26SA Pioneer CC1
26SH Sea King
26SK Skeeter
26SR Valiant B
26SS Swift
26SW Scout [& Wasp]
26TA Andover
26TD Dominie T
26TP Twin Pioneer
26TT Tiger Moth 2
26TV Varsity T1
26UU Wellington 1
26V Hart DB & India & T
26VA Harrier GR
26VC VC10C
26WA Argosy
26WW Whirlind (helicopter)
26WX Wessex

British hardware

28D Bolts A.G.S.
28E Clips A.G.S.
28F Couplings A.G.S.
28FP Aircraft Fastner and Quick Release Pins
28G Eyebolts A.G.S.
28H Ferrules A.G.S.
28J Filler Caps and Fuel Filters A.G.S.
28K Fork Joints A.G.S.
28L Locknuts, Lockwashers A.G.S.
28M Nuts A.G.S.
28N A.G.S. Miscellaneous A to O
28P Pins A.G.S.
28Q Rivets A.G.S.
28R A.G.S. Miscellaneous P to R
28S Screws A.G.S. Miscellaneous A to O
28T Studs A.G.S.
28U Trunnions and Turnbuckles A.G.S.
28V Unions A.G.S.
28W Washers A.G.S.
28X Wire A.G.S.
28Y A.G.S. Miscellaneous S to Z
29A Bolts and Nuts, General Hardware
29B Screws, General Hardware
29C Eyelets, Roves, Screw Cups, Washers, General Hardware
29E Pins, Woodruff Keys, General Hardware
29F Rivets, General Hardware





Aircraft Reference Numbers



Manufacturer Codes:

AS = Airspeed
AW = Armstrong Whitworth
R3 = Avro
BP = Boulton Paul (possibly EP)
FB = Bristol
DH = DeHaviland
EEP = English Electric Preston
F8 = Fairey Engineering
G5 = Gloster
HA = Hawker – also 41H?
HP = Handley Page
MCO = Morris Cowley Oxford
PAC = Percival Aircraft Corporation
PPA = Miles (Phillips & Powis)
R = Republic
SB = Short Brothers
SFR = Rootes Speke
SR = Saunders Roe
SHB = Short & Harland Belfast
SHR = Short & Harland Rochester
TAY = Taylorcraft
VA = Victory Aircraft
VACB = Vickers Armstrong Castle Bromwich
VACH = Vickers Armstrong Chester
VABL = Vickers Armstrong Blackpool
WA = Westland



Miscellaneous Codes:

AGS = Aircraft General Standard (Often on nuts and bolt heads)
ALCLAD = Aluminium (Or “Alooominum” if from former colonies!)
ALCOA = Aluminium Corporation of America
PSC = Pressed Steel Company






Aircraft Part Codes:

P39 = Airacobra (Bell) AW41 = Albermarle Mk1
652A = Anson (All Mk’s) 660 = Argosy
UC61 = Argus Mk1 (Fairchild) UC61A= Argus Mk II
UC61K= Argus Mk III 701 = Avro Athena T2
540 = Avro 504K 582 = Avro 504N

187 = Baltimore (Martin) 156 = Beaufighter Mk1F
152 = Beaufort 192 = Belvedere (Westland)
B101 = Beverley (Blackburn) C1 555 = Bison
142M = Blenheim Mk IF 149 = Blenheim Mk Ib
160 = Blenheim Mk V 130A = Bombay
B26 = Botha 164 = Brigand
F2A = Bristol Fighter B103 = Buccaneer
B339E = Brewster Buffalo 105A = Bristol Bulldog Mk II & IIa

EA3 = Canberra B2 EA2 = Canberra PR3
EA4 = Canberra Mk24 SC4 = Canberra U/D 10
28 = Catalina Mk I CH47 = Chinook HC1
DHC1 = Chipmunk T10 DH60 = Cirrus Moth Mk I & II
DH106 = Comet Mk I – IV 20 = Commando

C47 = Dakota Mk I C53 = Dakota Mk II
C47A = Dakota Mk III C47B = Dakota Mk IV
P82 = Defiant DH104 = Devon
89A = Dominie Mk I ‘(B = Dominie Mk II

AS10 = Envoy Mk III 229 = Fortress Mk I

60M = Gipsy Moth

HP57 = Halifax Mk I HP59 = Halifax Mk II
HP61 = Halifax Mk III HP63 = Halifax Mk IV
HP63 = Halifax Mk V HP70 = Halifax Mk VIII
HP71 = Halifax Mk IX HP52 = Hampden Mk I
HP54 = Harrow NA16 = Harvard I
NA66 = Harvard II NA88 = Harvard IIa
AT16 = Harvard IIb HP67 = Hastings
HP94 = Hastings C4 DB7 = Havoc I
DB7A = Havoc Mk II P1182 = Hawk (BAe)
C130K = Hercules (Lockheed) HP50 = Heyford
DH103 = Hornet AS51 = Horsa (Also marked AS58)
L-214 = Hudson Mk I L-414 = Hudson Mk II-VI
P1067 = Hunter Mk I P1099 = Hunter Mk6
P1101 = Hunter T7

TypeS = Jaguar TypeM = Jaguar T2
GA5 = Javelin 145 = Jet Provost

683 = Lancaster (All Mks) 691 = Lancastrian
32 = Liberator 22 = Lightning (P-38)
P1B = Lightning Mk IF P25 = Lightning Mk 2F
P26 = Lightning Mk 3F P11 = Lightning T4
P27 = Lightning T5 694 = Lincoln
P8 = Lysander

M14 = Magister Mk I 679 = Manchester
179 = Marauder M25 = Martinet TT1
M9 = Master Mk I M19 = Master Mk II
M27 = Master Mk III M16 = Mentor
G41A = Meteor Mk I G41F = Meteor F4
G43 = Meteor T7 G41K = Meteor F8
G41L = Meteor FR9 G41M = Meteor PR10
NA62B= Mitchell Mk I NA82 = Mitchell II
NA-108= Mitchell III 98 = Mosquito (All Mks)
NA73 = Mustang I (Also NA83) NA91 = Mustang Ia
NA102 = Mustang III NA109 = Mustang IV
NA97 = A-36 Apache (with dive brakes) NA99 = P-51A / Mustang II
NA103 = P-51C (early version) / Mustang III NA104 = P-51B (later version) / Mustang III
NA111 = P-51C (later version) / Mustang III
NA111 = P-51K-NT (early Dallas-built = Mustang IVA
NA122 = P-51D-NA (later version) / Mustang IV
NA124 = P-51D-NT (late version Dallas built) / Mustang IV

26 = Neptune HS801 = Nimrod (BAe)

AS10 = Oxford MkI & II AS46 = Oxford MkV

P66 = Pembroke F-4 = Phantom
P28 = Proctor I P30 = Proctor II
P34 = Proctor III P31 = Proctor IV

DH82B= Queen Bee (Pilotless?)

C1-13 = Sabre (F-86) 696 = Shackleton
382 = Spiteful 300 = Spitfire Mk I; Ia; Ib
329 = Spitfire Mk IIa & IIb 375 = Spitfire Mk IIc
353 = Spitfire Mk IV 332 = Spitfire Mk Vb
331 = Spitfire Mk Vb 349 = Spitfire Mk Vc & LF Vb
352 = Spitfire F Vb 351 = Spitfire Mk VII
359 = Spitfire Mk III 361 = Spitfire Mk IX
362 & 387 = Spitfire Mk X 365 = Spitfire Mk XI
366 = Spitfire Mk XII & XIII 367 & 353 = Spitfire Mk XIII
369 & 379 = Spitfire Mk XIV & XIVe 380 = Spitfire Mk XVI
394 = Spitfire Mk XVIII 389 & 390 = Spitfire Mk XIX
356 = Spitfire Mk F21; F22 & F24 SB29 = Stirling
S25 = Sunderland 541 = Swift (Shorts)
546 = Swift (Supermarine) 171 = Sycamore HA12

82 = Tiger Moth 81A-1 = Tomahawk Mk I
81A-2 = Tomahawk Mk II 621 = Tutor (Avro)
89 & 93 = Thunderbolt





637 = Valetta 706 & 710 = Valiant
100 = Vampire Mk F1; F3; F5; F9 113 = Vampire NF10
115 = Vampire T11 668 = Varsity
112 = Venom V146 = Ventura
237 = Ventura Mk V HP80 = Victor
498 = Viking C2 FB27 = Vimy Mk IV
698 = Vulcan

236 = Walrus 462 = Warwick ASR Mk I
413 & 611 = Warwick II 460 = Warwick III
474 & 475 = Warwick V 485 = Warwick ASR Mk VI
345 = Washington B1 P14 = Welkin
287 = Wellesley 285 & 290 = Wellington I
408 & 409 = Wellington Ia 415 & 450 = Wellington Ic
298 & 406 = Wellington II 417 & 440 = Wellington III
410 & 424 = Wellington IV 407 & 421 = Wellington V
442 & 449 = Wellington VI 429 = Wellington VIII
440 = Wellington X 454 & 458 = Wellington XI
455 = Wellington XII 466 = Wellington XIII
467 = Wellington XIV P9 = Whirlwind
188 & 38 = Whitley Mk I 197 = Whitley II
205 = Whitley III 209 & 210 = Whitley IV & IVa
207 = Whitley V 217 = Whitley VII
244 = Wildebeeste I 258 = Wildebeeste II
267 = Wildebeeste III 286 = Wildebeeste IV

685 = York C1


Air Ministry Equipment Codes:

No. 5 = Electrical Equipment No.6 = Nav. & optical Equipt.
No.6A = Aircraft Instruments
No.6D = Oxygen Equipment No.6F = Aircraft Personnel Equipt.
No. 7; 8; 9 = Aircraft Armaments No.10 = Comms. Equipt.
No.11 = Bombing Gear No.12A= Bombs (Live)
No.12B= Bombs (Dummy) No.12C= Ammunition
No.12E = Torpedoes No. 12F= Misc. Armament
No.14 = Photo Equipment No.15A = Man-carrying parachute Equip.
No. 15C= Equipt Drop & Sea-Dropping Apparatus No.15D = Supply Drop & ASR Equipt.
No. 22C= Flying Clothing No.27C= Survival Equipment

6A Aircraft Engine and Flying Instruments, Accessories and Spares
6B Aircraft Navigation Equipment, Accessories and Spares
6C Instrument Test Equipment, Tools, Accessories and Unit Equipment Spares
6D Aircraft Gaseous Apparatus and Ancillary Equipment
6E Miscellaneous Instruments, Accessories and Unit Servicing Spares
6H Aircraft Automatic Pilots, Marks 4 and 8, Major Components, Servicing Spares and Tools
6J Aircraft Automatic Pilots, Types A3 and A3A and A.L.1, Major Components, Servicing Spares and Tools
6S Automatic Stabilisers, Major Components, Servicing Spares and Tools
6T Aircraft Automatic Pilots, Marks 9, 10, 10A, 13, SEP 2, 14 and 17, Major Components, Servicing Spares and Tools
6W Instrumemnt Ancillaries to Radio Equipment
6Z Radio activity Detection Equipment and Accessories, Unit and Major Servicing Spares
13 Drawing Instruments
52 Recognition Models
54A Plotting Equipment
5A Ground Lighting and Miscellaneous Equipment
5B Aircraft Wiring Assemblies
5CW Aircraft Electrical Switches, Switchboxes, Relays and Accessory Items
5CX Aircraft Electrical Lamps, Indicators, Lampholders and Accessory Items
5CY Aircraft Electrical Plugs, Sockets, Circuit Markers, Suppressors and Accumulator Cut-outs
5CZ Aircraft Electrical Miscellaneous Stores
5D Aircraft Armament Electrical Stores
5E Cable and Wire Electrical Stores
5F Insulating Materials Electrical Stores
5G Special Ground Equipment
5H Standard Wiring System
5J Batteries Primary and Secondary
5K Electrical A.G.S and Bonding Stores
5L Electric Lamps
5P Ground Charging, Transforming Equipment and Motors
5Q Ammeters, Micro-ammeters, Milli-ammeters, Voltmeters and Milli-voltmeters
5S Strip Wiring Components
5UA Aircraft Engine and Air Driven Electrical Current Producing Equipment and Spares
5UB Aircraft Electrically Driven Electrical Current Producing and Transforming Equipment and Spares
5UC Aircraft Electrical Current Control Equipment and Spares
5UD Aircraft Electrical Motors, Blowers and Spares
5UE Aircraft Electrically Driven Pumps, Accessories and Spares
5V Aircraft Electrical Domestic Equipment
5W Aircraft Electrical Actuators, Accessories and Spares
5X Component Parts of Wiring Assemblies
10A Miscellaneous Radio (Wireless) Equipment
10AB Miscellaneous Radio (Radar) Equipment
10AC Unassembled Items peculiar to Radio with Generic Headings similar to those in Sections 28 and 29
10AD Items and Assemblies performing Circuit Functions (Nomenclature commencing Letters A-K)
10AD Items and Assemblies performing Circuit Functions (Nomenclature commencing Letters L-Z)
10AF Calculating, Indicating and Measuring Equipment
10AG Tools and Tool Boxes peculiar to Radio
10AH Telephone Head Equipment, Microphones and Receivers
10AJ Mountings and their Component Parts
10AK Dials, Handles, Knobs,Plates, Escutcheon, Pointers, Pressbuttons and Scales
10AL Screens and Insulating Components and their Assemblies
10AM Labels (Radio)
10AP Boxes, Cases, Covers and Trays, other Cases, Transit
10AQ Furniture, Tentage, textile Materials and Ventilator Equipment, peculiar to Radio
10AR Machinery, Machine and Mechanical Parts other than those in Section 10AC
(Nomenclature commencing Letters A-K)
10AR Machinery, Machine and Mechanical Parts other than those in Section 10AC
(Nomenclature commencing Letters L-Z)
10AT Windows and Visors
10AU Strip Metallic
10B Radio (Wireless and Radar) Aerial and Mast Equipment and Insulators
10BB Radio (Radar) Aerial and Mast Equipment and Insulators
10C radio Chokes, Capacitors and Inductors (see also Joint-Service Catalogue)
10CV Joint Service Common Valves
10D Radio (Wireless and Radar) Equipment, Modulators, Panels, Receivers, Transmitters etc.
10DB Radio (Radar) Equipment, panels, Power Units, Racks, Receivers and Transmitters
10E Magnets and Radio Valves (Industrial Types)
10F Radio (Wireless and Radar) Starters and Switch Gear
10FB Radio (radar) starters and Switch Gear
10G Ground Telephone and Telegraph Equipment
10GP Ground Telephone and Telegraph Equipment - Post Office Pattern
10H Radio Connectors, Discs Indicating, Fuses, Leads, Plugs and Sockets and Ancillary Parts,
Holders and Terminals.
10HA Radio (Wireless and Radar) Connectors, Cords Instrument and Leads
10J Radio Remote Controls
10K Radio (Wireless and Radar) Power Units and Transformers
10KB Radio (Radar) Power Units and Transformers
10L Radio (Wireless and Radar) Control Units
10LB Radio (Radar) Control Units
10P Radio (Wireless and Radar) Filter and Receiver Units
10PB Radio (Radar) Filter and Receiver Units
10Q Radio (Wireless and Radar) Indicating Units
10QB Radio (Radar) Indicating Units
10R Radio (Wireless and Radar) Transmitter Units
10RB Radio (Radar) Transmitter Units
10S Radio (Wireless and Radar) Test Equipment
10SB Radio (Radar) Test Equipment
10T Radio Monitors and Wavemeters
10U Radio (Wireless and Radar) Amplifying Units, Loudspeakers and Sound Reproduction Equipment
10UB Radio (Radar) Amplifying Units and Loudspeakers
10V Radio (Wireless and Radar) Oscillator Units
10VB Radio (Radar) Oscillator Units
10W Radio Resistors and miscellaneous Spares
10X Radio Crystal Units
10Y Cases Transit (general Radio purposes)
9 Bomb and Torpedo Sights
9A Aircraft Towed Target Gear
9B Armament Ground Instructional Equipment
11A Aircraft Bomb Gear
11C Rocket Projector Gear
40H Gun Turret Cases and Airtight Containers
50A Aircraft Gun Turrets
50CC Boulton Paul Gun Turret and Gun Mounting Tools
50DD Bristol Gun Turret Tools
50EE Frazer Nash Gun Turret Tools
50H Aircraft Gun Turret Maintenance Equipment
50J Free Gun Mountings
14A Cameras
14B Photographic Processing Equipment, Enlargers and Accessories
14C Projection, Assessing Apparatus and Epidiascopes
14H Photographic Test Apparatus
6F Aircraft Personnel Equipment
15A Man-carrying Parachutes
15C Equipment-dropping and Sea-rescue Apparatus
15D Air Sea Rescue and Equipment, and Supply-dropping Parachutes
25A Propellors
25B Aircraft Radiators
25D Spinners for Fixed Pitch Propellers and Fairey Spares for Metal Propellers
27A Aircraft Wheel Equipment
27B Aircraft Air and Oil Filters, Fuel and Oil Coolers
27D Miscrellaneous Aircraft Cover Equipment
27F Aircraft Pumps and fuelling Equipment (Airborne)
27G Aircraft Brake System Equipment
27H Miscellaneous Aircraft Equipment
27J Aircraft Control Handles with Gun, Camera, R.P. and Brake Operating Mechanisms
27K Teleflex Aircraft Remote Control Equipment
27KA Exactor Aircraft Remote Control Equipment
27KB Aircraft Controls - Roller Chains
27KD Pressurised Cabin Equipment - Normalair
27M Aircraft Hydraulic and Undercarriage Equipment - Lockheed
27N Airborne Fire Fighting Equipment
27R B.L.G. Oleo Leg Equipment
27S Standard Ball and Roller Bearings other than M.T.
27T Controllable Gills
27U Airborne Heaters
27UA Aircraft Cabin Cooling Equipment
27V Aircraft Controls - Teddington
27VA Aircraft Controls - Dunlop
27VC Aircraft Controls - Palmers
27W Aircraft Hydraulic and Undercarriage Equipment, Standard Design
27WW Aircraft Windscreen Wiper Equipment
27Z Turner Duplex Hand Pumps for Aircraft Hydraulic Systems
27ZA Exactor Self Sealing Couplings
28D Bolts A.G.S.
28E Clips A.G.S.
28F Couplings A.G.S.
28FP Aircraft Fastner and Quick Release Pins
28G Eyebolts A.G.S.
28H Ferrules A.G.S.
28J Filler Caps and Fuel Filters A.G.S.
28K Fork Joints A.G.S.
28L Locknuts, Lockwashers A.G.S.
28M Nuts A.G.S.
28N A.G.S. Miscellaneous A to O
28P Pins A.G.S.
28Q Rivets A.G.S.
28R A.G.S. Miscellaneous P to R
28S Screws A.G.S. Miscellaneous A to O
28T Studs A.G.S.
28U Trunnions and Turnbuckles A.G.S.
28V Unions A.G.S.
28W Washers A.G.S.
28X Wire A.G.S.
28Y A.G.S. Miscellaneous S to Z
29A Bolts and Nuts, General Hardware
29B Screws, General Hardware
29C Eyelets, Roves, Screw Cups, Washers, General Hardware
29E Pins, Woodruff Keys, General Hardware
29F Rivets, General Hardware
4A Workshop Equipment
4C Airfield Equipment
4F Air Compressors and Servicing Trolleys
4G Aircraft Servicing and Ground handling Equipment
4K General Ground Equipment (including Refuelling Equipment)
4N Sparking Plug Testing and Servicing Equipment
4FZ Air Compressor Spares
71B Plants (Mobile, Transportable and Static) and Plant Accessories

__________________









                                     Spitfire instrument panels by Herbert Puuka



Differences between the Mk versions of Merlin-powered Spitfires:



Mk I

Early oxygen regulator

hole for landing light

Gunsight and generator switch

One starter button

Fuel pressure gauge or warning lamp with adapter plate

Round temperature gauges

One or two round fuel gauges



Mk II

Early oxygen regulator

hole for landing light

Gunsight and generator switch

One starter button

Fuel pressure gauge or warning lamp with adapter plate

Round temperature gauges

Round fuel gauge

Hole for cardridge starter handle



Mk V

Early oxygen regulator

With or without hole for landing light

Gunsight switch

Two starter buttons

Fuel pressure gauge or lamp

Round temperature gauges

Round fuel gauge



Mk IX

Early or late oxygen regulator

Two starter buttons

Supercharger panel

Fuel pressure warning lamp

Round or rectangle temperature gauges

Round or rectangle fuel gauges



Conclusion:

After some time of research and collecting cockpit pictures I discovered, that the Mk V panels introduced the boost coil switch

and the hole for the cartridge starter handle disappeared. Together with the two-speed supercharger engines appeared the

supercharger panel of the Mk. IX and later Mks. The generator switch disappeared with Mk V, the gunsight switch with

 Mk IX. I seem to have no picture of a metal panel so the change to Paxoline panels took place very early.

Voltage information supplied by Spitfire Spares member Dave. Instrument voltage is generally marked on the case and this info will be invaluable when identifying instrument use.

 Spitfire IX - 12v
Spitfire XXII - 12V
Spitfire 14 - 12V
Spitfire 16 - 12V
Spitfire 19 - 12V
Spitfire 22 & 24 - 24V
Wellington - 24V
Beaufighter - 24V
Lincoln - 24V
York - 24V
Dakota I -12V
Dakota III - 24V
Anson I - 12v
Anson 22 - 24V
Lancaster - 24V
Stirling - 24V
Halifax -24V
Varsity - 24V
Sea Fury - 24V
Tempest II -24V
Meteor III - 24V
Mosquito - 24V
Vampire - 24V
Harvard - 12v
Oxford - 12v
Hornet - 24v
Canberra - 24v
Chipmunk - 24V
Mustang - 24v
Hurricane - 12V

Supermarrine Spitfire part Numbers.

Spitfire part numbers are 7 digit numbers always starting with 3. The first 3 digits tells you the Mk of aircraft 1e 300 =Mk 1 although the number was only changed if the part was modified. Therefore you still get 300 part numbers on later aircraft. The second set of digits relates to the type of part i.e. airframe, fuel ect. The last 2 digits are the actual part number, relating to that individual part. This only applies to Supermarrine (Spitfire only) parts. The Spitfire is also full of hundreds of standard air ministry parts which don't carry the 300 numbers, all the instruments are A/M parts except the trim gauge which carry's a 300 part number, this explains why its so rare because it was ONLY used in Spits.

Example 300 45 **

300 = Mk1 Spitfire

45 =Petrol Tanks

**= Individual part number

This is a part I dug up at my airfield. I found lots of these parts and did not have a clue what they were until one day I found one with a bung in it and the magic Spitfire number.

3006580

According to the parts list its an original Mk1 part i.e. 300( could be fitted to any Mk if this part was not modified). The 65 means it was petrol tank auxiliary. 80 is the part number. My guess is this is a drop tank part. This would tie in nicely with Culmhead as allot of Spitfires operated with drop tanks from this field. On D-Day Seafires fitted with drop tanks escorted Typhoons on ground attack missions.

Sdr Ldr Glaser DFC mentioned earlier in the reference section was training with drop tanks at Culmhead.

 Allot of the missions flown from Culmhead would have required the use of drop tanks.

List of instruments Spitfire Mk XIV

Dunlop air pressure gauge AHO 4040
Tail trimming indicator 30034
Master switch 5C/1974
Ignition switch box 5C/548
Tail wheel warning lamp 35136 flange plate 5C/1553 or 5C/1069
Dimmer switches 5C/367
Time of flight clock 6A/579 or 6A/1150 or 6A/1002
Undercarriage indicator 30036 5C/1731
Oxygen regulator 6D/513 or 6D/695
Flap control valve 34959
Terminal block 5C/430
Gunsight dimmer switch 5C/763
Gunsight socket 5C/892
Voltmeter 5A/1636
Engine speed indicator 6A/450 or 6A/1191
Dunlop pipe connection AHO 2790
Supercharger switch 10H/11714
Supercharger warning lamp 5C/1553 or 5C/1069
Boost gauge 6A/1427 or 6A/1581
Oil pressure gauge 6A/536
Oil thermometer 6A/1094 or 6A/1340
Radiator thermometer 6A/1100 or 6A/1480
Fuel pressure warning lamp 35136 flange plate 5C/1553 or 5C/1069
Fuel content warning lamp 35136 flange plate 5C/1553 or 5C/1069
Fuel content gauge 6A/1569 727 FG
Starter switch 5C/540 or 5C/898
Starter switch flap cover 36134 or 5C/1267
Compass deviation card holders 6A/387

BFP:
Air Speed indicator 6A/587
Artificial horizon 6A/589 or 6A/1488 or 6A/711
Rate of climb meter 6A/942
Altimeter 6A/577 or 6A/685 or 6A/1203
Direction indicator 6A/602 or 6A/1209
Turning indicator 6A/675

Control Grip info by Herbert Puukka

A.P.1086, Part 11E lists the following "ring control handles" for the Spitfire:
AH2174 for Spitfire IA, IIA, VA
AH8068 for Seafire, Spitfire IB, IIB, VB, VC, F.VI, VII, VIII, FIX, FXII, FXXI


AH2174 Spitfire IA, IIA, VA

AH8068 Seafire, Spitfire IB, IIB, VB, VC, FVI, VII, VIII, FIX, FXII, FXXI

AH2040 with brake lever: Hurricane, Battle, Fulmar, Lysander I and II, Skua, Swordfish and Whirlwind.

AH2242 Harvard I and II

AH8272 Firefly, Firebrand and Sea Hornet

The AH References are Dunlop's own and they are usually to be found stamped onto the lower portion of the grip. The first listed one is for the classic round, pneumatic gun firing button, the latter is for the selective twin pneumatic switch.

If it is Spitfire it will have a brake lever on the back. No lever or mounting pin then again most probably a Canadian Harvard that had toe brakes.

Hurricane grips should have the pipe work external to the grip, i.e. it doesn't go through the hole in the top of the control column.

A proper grip for the Harvard I and II should be stamped AH2242, a proper Hurricane, AH2040.

For the record, AH2040 also "fits" the Battle, Fulmar, Lysander I and II, Skua, Swordfish and Whirlwind

        Instrument info by Herbert Puukka

                                                                        MK XIV Spitfire Instrument list.

Dunlop air pressure gauge                   AHO 4040

Tail trimming indicator                        Supermarine 30034

Master switch                                       5C/1974

Ignition switch box                              5C/548

Tail wheel warning lamp                     35136 flange plate 5C/1553 or 5C/1069

Dimmer switches                                 5C/367

Time of flight clock                             6A/579 or 6A/1150 or 6A/1002

Undercarriage indicator                        Supermarine 30036  5C/1731

Oxygen regulator                                 6D/513 or 6D/695

Flap control valve                                34959

Terminal block                                     5C/430

Gunsight dimmer switch                      5C/763

Gunsight socket                                    5C/892

Voltmeter                                             5A/1636

Engine speed indicator                        6A/450 or 6A/1191

Dunlop pipe connection                       AHO 2790

Supercharger switch                             10H/11714

Supercharger warning lamp                  5C/1553 or 5C/1069

Boost gauge                                          6A/1427 or 6A/1581

Oil pressure gauge                                6A/536

Oil thermometer                                    6A/1094 or 6A/1340

Radiator thermometer                           6A/1100 or 6A/1480

Fuel pressure warning lamp                  35136 flange plate 5C/1553 or 5C/1069

Fuel content warning lamp                    35136 flange plate 5C/1553 or 5C/1069

Fuel content gauge                                 6A/1569    727 FG

Starter switch                                         5C/540 or 5C/898

Starter switch flap cover                        36134 or 5C/1267

Compass deviation card holders             6A/387



BFP:

Air Speed indicator                                6A/587

Artificial horizon                                   6A/599 or 6A/1488 or 6A/711

Rate of climb meter                               6A/942

Altimeter                                                6A/577 or 6A/685 or 6A/1203

Direction indicator                                 6A/602 or 6A/1209

Turning indicator                                   6A/675



   Instrument List Mk1 to MKIX Spitfire

 Dunlop air pressure gauge                   AHO 4040

Tail trimming indicator                        30034

Ignition switch box                              5C/548

Dimmer switches                                 5C/367

Time of flight clock                             6A/579 or 6A/1150 or 6A/1002

Undercarriage indicator                        30036  5C/1731

Oxygen regulator                                 6D/513 or 6D/695

Switchbox                                            5C/543

Flap control valve                                34959

Gunsight dimmer switch                      5C/763

Gunsight socket                                    5C/892

Voltmeter                                             5A/1636

Engine speed indicator                        6A/450

Supercharger switch                             10H/11714

Supercharger warning lamp                  5C/1553 or 5C/1069

Boost gauge                                          6A/789

Fuel pressure gauge                              6A/512

Oil pressure gauge                                6A/556

Oil thermometer                                    6A/155

Radiator thermometer                           6A/494

Fuel pressure warning lamp                  35136 flange plate 5C/1553 or 5C/1069

Fuel content gauge                                 6A/703

Fuel gauge pushbutton switch               6A/646

Starter switch                                         5C/540

Starter switch flap cover                        32936

Compass deviation card holders             6A/387



BFP:

Air Speed indicator                                6A/563 or 6A/587

Artificial horizon                                   6A/599 or 6A/1488 or 6A/711

Rate of climb meter                               6A/723 or 6A/942

Altimeter                                                6A/577 or 6A/685 or 6A/1203

Direction indicator                                 6A/602 or 6A/1209

Turning indicator                                   6A/675



                                                      MkII Hurricane instrument list

 Engine starter pushbutton                                        5C/898

Booster coil pushbutton                                            5C/898

Boost control cut-out

Time of flight clock                                                     6A/581

Oxygen regulator                                                        Mk VIII (6D/513)

Undercarriage indicator switchbox                          5C/1991

Undercarriage indicator                                            5C/4845

Compass deviation card holders                             6A/387

Instrument flying panel                                               6A/616

Engine speed indicator                                             6A/450

Reflector sight switchbox                                          5C/543

Boost gauge                                                              6A/486 or 6A/699 or 6A/789

Fuel contents gauge selector switch                       6A/1113

Fuel contents gauge (28 and 33 gallons)               6A/792 or 6A/812 or 6A/813

Fuel pressure gauge/warning light                           6A/512 or 5C/1553 or 5C/1069

Oil thermometer                                                         6A/155

Radiator temperature gauge                                    6A/494

Oil pressure gauge                                                    6A/311

3-Switchbox                                                                5C/544

Ignition switchbox                                                       5C/548

Magneto switchbox (only MK I)                                 5C/547



BFP:

Air Speed indicator                                                    6A/583 or 6A/1293

Artificial horizon                                                          6A/599 or 6A/711

Rate of climb meter                                                    6A/723 or 6A/942

Altimeter                                                                      6A/577 or 6A/685

Direction indicator                                                      6A/602

Turning indicator                                                         6A/675



Thanks  to Herbert for this valuable info that must have taken many hours to research



Lancaster Ammunition Assistance

See this at Armaments page 2





1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17


















 © Copyright 2003.  SpitfireSpares.com.  All Rights Reserved.
